LED street light SILVA ECO

The SILVA ECO luminaire is an energy-saving lighting solution for public spaces, car parks and company premises.

Category: LED Public Lighting

Features

Key features	option to adjust the tilt angle (± 15°) variety of versions – various power ratings and beam angles available low glare simple installation photobiologically safe environmentally friendly lighting
Efficacy	up to 160 lm/W at a colour temperature of 4,000 K and a colour rendering index (Ra) > 70
Maximum luminous output	from 2,600 lm to 10,875 lm
Lifetime	100,000 hours L90B10 while maintaining 90 % of the initial luminous flux
Warranty	5 years

Varianty

Model	Dimensions	Number of modules	Power	Luminous flux (WW)*	Luminous flux (NW)*	Weight
SILVA ECO	559 × 216 × 93 mm	1	18 – 41 W	2,525 – 5,300 lm	2,600 – 5,450 lm	3.8 kg
SILVA ECO	559 × 216 × 93 mm	2	35 – 78 W	5,075 – 10,575 lm	5,225 – 10,875 lm	3.8 kg

* The luminous flux is stated including luminaire losses (not the flux of the LED chips themselves). The luminous flux depends on the selected colour temperature (in kelvins) – the higher the temperature, the higher the luminous flux. [3,000 K = warm white (WW), 4,000 K = neutral white (NW), 5,000 K = daylight white (DW), 6,000 K = cool white (CW)]

The luminaire is made in several power levels. The luminous flux also depends on the selected optics – exact values for each power rating and optic can be found in the LDT data in the Downloads tab.

Technical data

Luminaire design

Luminaire body:	aluminium
Diffuser:	tempered glass

Colour temperature

4,000 K (3,000 – 6,500 K on request)

Colour rendering index

> 70 CRI

Beam angle

Curve B*
Curve S*
Curve KM1*
Curve KM2*
Curve KS1*
Curve KS2*
Curve PR*
Curve PL*

Operating temperature

-25 °C ~ 40 °C

27, 31, 35, 41 and 78 W: -40 °C ~ 40 °C

Input voltage

AC: 220 V – 240 V/50 – 60 Hz

Protection rating

IP 66

Impact resistance

IK 09

Protection class

I (II on request)

* B – asymmetric curve for billboard lighting, S – asymmetric curve for sports ground lighting, KM and KS – asymmetric curves for road lighting, PR and PL – asymmetric curves for pedestrian crossing lighting

Accessories and mounting

Accessories

wall bracket (optional)
pole adapter (Ø 48 mm)
pole adapter (Ø 76 mm)

Mounting method

horizontal pole (Ø 60 mm)
vertical pole (Ø 60 mm)
on the wall

Luminaire options

Dimming:	DALI
Control:	photocell, NEMA / Zhaga connector

Downloads

Catalogue sheets	Catalogue sheet – SILVA ECO luminaire
LDT data	LDT data for the SILVA ECO luminaire

The benefits of SILVA ECO LED luminaires include lower energy costs and a lifetime of more than 100,000 hours. The aluminium body ensures high durability (protection ratings IK 09 and IP 66). It naturally offers low glare.

SILVA ECO features simple installation. When mounted on a horizontal or vertical pole, the tilt angle can be adjusted (±15°). Another advantage is the variability of versions of the luminaire – various power ratings and beam angles are available.

The luminaire is environmentally friendly and resistant to UV radiation, ozone and mains voltage fluctuations. It starts without delay and without flicker.

SILVA ECO luminaires come with a 5-year warranty.
