LED Ceiling Light SANTOS

SANTOS is a design lighting solution for interiors: offices, entrance halls, meeting rooms, receptions, corridors, shops, schools and hotels.

Categories: Sensor LED Lights, Wall LED Lights

Features

Key features	design circular luminaire suitable for interiors high-quality steel luminaire body energy-saving and elegant lighting solution low glare (UGR < 19) available in various colour finishes (RAL)
Efficacy	up to 147 lm/W at a colour temperature of 4,000 K and a colour rendering index (Ra) > 80
Maximum luminous output	from 2,000 lm to 21,075 lm
Lifetime	50,000 hours L80B10 while maintaining 80 % of the original luminous flux
Warranty	5 years

Varianty

Model	Dimensions	Power	Luminous flux*		Weight
Model	Dimensions	Power	(WW)*	(NW)*	Weight
SANTOS 30	Ø 300 mm × 100 mm	16 W	1,925 lm	2,000 lm	2.5 kg
SANTOS 30	Ø 300 mm × 100 mm	21 W	2,625 lm	2,725 lm	2.5 kg
SANTOS 45	Ø 450 mm × 100 mm	30 W	3,875 lm	4,050 lm	4.2 kg
SANTOS 45	Ø 450 mm × 100 mm	44 W	5,275 lm	5,525 lm	4.2 kg
SANTOS 60	Ø 600 mm × 100 mm	45 W	5,950 lm	6,225 lm	7.1 kg
SANTOS 60	Ø 600 mm × 100 mm	64 W	8,100 lm	8,575 lm	7.1 kg
SANTOS 90	Ø 900 mm × 150 mm	73 W	10,050 lm	10,525 lm	14.1 kg
SANTOS 90	Ø 900 mm × 150 mm	94 W	12,825 lm	13,425 lm	14.1 kg
SANTOS 115	Ø 1.150 mm × 150 mm	112 W	15,775 lm	16,500 lm	22.8 kg
SANTOS 115	Ø 1.150 mm × 150 mm	146 W	20,125 lm	21,075 lm	22.8 kg

* The luminous flux already includes luminaire losses (we do not state the luminous flux of the LED chips themselves). The luminous flux depends on the selected colour temperature (in kelvins) – the higher the temperature, the higher the luminous flux. [3,000 K = warm white (WW), 4,000 K = neutral white (NW), 5,000 K = daylight white (DW), 6,000 K = cool white (CW)]

Technical data

Luminaire design

Luminaire body:	white steel sheet (RAL 9003)
Diffuser:	opal light-guiding (micro-prismatic on request)

Colour temperature

3,000 K alebo 4,000 K

Colour rendering index

> 80 CRI (> 90 CRI on request)

Beam angle

107°

Operating temperature

0 °C ~ 35 °C

Input voltage

AC: 220 – 240 V/50 – 60 Hz

Protection rating

IP 40

Impact resistance

IK 02

Accessories and mounting

Accessories

decorative cable cover (on request)

white, grey or black finish

Mounting method

surface mounting on the ceiling
suspension (on request)

Luminaire options

Dimming:	on request (DALI)
Emergency lighting module:	on request (3 h)
Sensors:	on request (MW, corridor function)

Downloads

Catalogue sheets	Catalogue sheet – SANTOS luminaire
LDT data	LDT data for the SANTOS luminaire

The SANTOS LED luminaire is a high-quality and reliable interior lighting solution. It is designed for surface mounting; suspension accessories can be ordered separately on request.

SANTOS guarantees a lifetime of more than 50,000 hours and significant energy savings. Low glare (UGR < 19) allows it to be used in spaces with high demands on glare limitation – schools, kindergartens, offices, receptions and shops.

The DALI lighting control system is optional. The luminaire can be supplied with an emergency lighting module.

SANTOS luminaires come with an extended 5-year warranty.
