Wall LED Light NELA

The Wall LED Light NELA is a cost-saving and elegant lighting solution for offices, conference rooms, hotels, commercial premises, corridors and restaurants.

SKU: f86238a3fbb1 Category: Wall LED Lights

Features

Key features	luminaire suitable for indoor use high cost savings direct + indirect light distribution (50 % downward + 50 % upward)
Efficacy	up to 115 lm/W at a colour temperature of 4,000 K and a colour rendering index (Ra) > 80
Maximum luminous output	from 1,450 lm to 5,425 lm
Lifetime	50,000 hours L80B10 while maintaining 80 % of the initial luminous flux
Warranty	5 years

Varianty

Model	Dimensions	Power	Luminous flux (NW)*	Weight
NELA 60	580 × 85 × 75 mm	13 W	1,450 lm**	2.0 kg
		18 W	1,975 lm**
		26 W	2,725 lm**
NELA 90	860 × 85 × 75 mm	19 W	2,150 lm**	2.5 kg
		27 W	2,950 lm**
		39 W	4,075 lm**
NELA 115	1,140 × 85 × 75 mm	25 W	2,875 lm**	3.0 kg
		36 W	3,925 lm**
		51 W	5,425 lm**

* The luminous flux is stated including the losses on the luminaire (we do not state the luminous flux of the LED chips themselves). The luminous flux intensity depends on the selected colour temperature (in kelvins) – the higher the temperature, the greater the luminous flux. [3,000 K = warm white (WW), 4,000 K = neutral white (NW), 5,000 K = daylight white (DW), 6,000 K = cool white (CW)]

** Direct and indirect light distribution – 50 % of the stated luminous flux is directed downward and 50 % upward.

Technical data

Luminaire design

Luminaire body:	light grey aluminium profile (powder-coated, RAL 9006)
Diffuser:	opal polycarbonate diffuser

Colour temperature

4,000 K (3,000 K on request)

Colour rendering index

> 80 CRI

Beam angle

101° × 105°

the same curve downward and upward
50 % of the flux down, 50 % up

Light distribution curve of the Wall LED Light NELA

Operating temperature

-15 °C ~ 35 °C

Input voltage

AC: 220 – 240 V/50 – 60 Hz

Protection rating

IP 40

Impact resistance

IK 05

Protection class

Accessories and mounting

Accessories

opal diffuser with high light transmittance

Mounting method

surface-mounted on the wall

Luminaire options

Dimming:	on request (DALI, bluetooth)
RAL colour:	on request

Downloads

Catalogue sheets	Catalogue sheet – NELA luminaire
LDT data	LDT data for the NELA luminaire

Its biggest benefit is up to 70 % savings on energy and maintenance costs. The lifetime of the luminaire is really long – more than 50,000 hours.

The NELA luminaire is fitted with an opal diffuser that diffuses the light. The individual light sources (LED chips) are not visible and the luminaire provides pleasant, uniform lighting of the space without multiple shadows.

Thanks to the direct and indirect light distribution of the NELA luminaire, you get even and pleasant lighting of the space – without glare and the so-called “cave effect”.

The NELA luminaire is characterised by true colour rendering – its colour rendering index is higher than 80. People feel comfortable in the lit space, as the real colours of objects are not distorted. Thanks to its high efficacy of up to 115 lm/W at a colour temperature of 4,000 K, the luminaire lights the space efficiently.

The luminaire is resistant to mains voltage fluctuations and very easy to install. NELA is a high-quality and reliable lighting solution designed for surface mounting on the wall.

The luminaire comes with an extended 5-year warranty.
