Linear LED Light PERUN L

The PERUN L LED luminaire is an economical and highly efficient solution for lighting production halls, warehouses, shops and sports facilities.

SKU: 1a64588b49da Category: LED linear industrial lighting

Features

Key features	ideal replacement for linear fluorescent tubes T5 and T8 for medium-high and high halls or production spaces durable and suitable for demanding conditions resistance to deformation and aggressive environments pleasant uniform lighting faithful colour rendering
Efficacy	až do 185 lm/W at colour temperature 4 000 K and colour rendering index (Ra) > 80
Maximum luminous output	from 10 250 lm to 42 150 lm
Lifetime	100 000 hours L80B10 maintaining 80 % of the original luminous flux
Warranty	5 years

Variants

Model	Dimensions	Power	Luminous flux (NW)*	Operating temperature	Weight
PERUN L 100	940 × 80 × 115 mm	57 W	10 250 lm	-20 °C ~ 40 °C	1,5 kg
PERUN L 100	940 × 80 × 115 mm	68 W	12 125 lm	-20 °C ~ 35 °C	1,5 kg
PERUN L 120	1 195 × 80 × 115 mm	84 W	15 375 lm	-20 °C ~ 40 °C	2,2 kg
		101 W	18 175 lm	-20 °C ~ 35 °C	2,2 kg
		119 W	21 075 lm	-20 °C ~ 35 °C	2,2 kg
PERUN L 150	1 447 × 80 × 115 mm	111 W	20 500 lm	-20 °C ~ 40 °C	2,8 kg
		133 W	24 250 lm	-20 °C ~ 35 °C	2,8 kg
		146 W	26 100 lm	-20 °C ~ 35 °C	2,8 kg
		159 W	27 950 lm	-20 °C ~ 35 °C	2,8 kg
PERUN L 200	1 955 × 80 × 115 mm	168 W	30 750 lm	-20 °C ~ 40 °C	4,1 kg
		202 W	36 375 lm	-20 °C ~ 40 °C	4,1 kg
		238 W	42 150 lm	-20 °C ~ 35 °C	4,1 kg

* The luminous flux already includes the losses on the luminaire (we do not state the luminous flux of the LED chips themselves). The luminous flux intensity depends on the selected colour temperature (in kelvins) – the higher the temperature, the higher the luminous flux. [3 000 K = warm white (WW), 4 000 K = neutral white (NW), 5 000 K = daylight white (DW), 6 000 K = cool white (CW)]

Technical data

Luminaire construction

Luminaire body:	white sheet metal profile
Optics:	PMMA

Colour temperature

4 000 K (3 000 – 6 500 K on request)

Colour rendering index

> 80 CRI

Beam angle

40°
60°
75°
120°
30° × 65°
90° × 90°
asymmetric optics

Input voltage

AC: 220 V – 240 V/50 – 60 Hz

Power factor

≥ 0,95

Protection rating

IP 65

Impact resistance

IK 08 (IK 10 with protective grille)

Protection class

Accessories and mounting

Accessories

suspension bracket (optional)
adjustable ceiling and wall bracket (optional) angle adjustment within ±75°
suspension kit (optional)
protective grille (optional)

Mounting method

surface ceiling mounting
suspended
wall installation

Luminaire options

Dimming:	on request (DALI)
Emergency lighting module:	on request (3 h) emergency lighting operating temperature 0 °C ~ 35 °C
Sensors:	on request (OC/LUX, PIR)
Corridor function:	on request gradual slow switching on and gradual slow switching off of the luminaire

Downloads

Catalogue sheets	Catalogue sheet – PERUN L luminaire
LDT data	LDT data for PERUN L luminaire

The LED linear luminaire PERUN L is suitable for medium-high and high halls or production spaces. Its lifetime is more than 100 000 hours. Svietidlo je odolné a vhodné do náročných podmienok – je možné použiť ochrannú mriežku.

LED svietidlo PERUN L obsahuje kvalitné LED čipy značky Samsung a jeho efficacy is up to 185 lm/W pri teplote svetla 4 000 K a indexe podania farieb väčšom ako 80. Neprodukuje UV žiarenie a rešpektuje životné prostredie. Nepotrebuje údržbu a pri jeho používaní nenastávajú problémy s oneskoreným štartovaním, blikaním or vysokofrekvenčným rušením.

Voliteľné sú:

a dimmable power supply (DALI),
an OC/LUX motion sensor or a PIR sensor,
an emergency lighting module (3 h),
a corridor function, which ensures gradual switching on of the luminaire upon motion detection – a „soft start“ – as well as gradual slow switching off of the luminaire.

The PERUN L LED luminaire is a quality and reliable lighting solution. It comes with a 5-year warranty.
