Linear LED Light LENA ECO+ ABS

LENA ECO+ ABS is a chemically resistant dustproof luminaire for production halls, workshops, laboratories and food processing plants.

Category: LED linear industrial lighting

Features

Key features	chemically resistant ABS base and acrylic diffuser protection rating IP 66 / IP 69 – resistant to pressurised water HACCP certified for the food industry ML versions with adjustable luminous flux (multilumen) ceiling, wall or suspended mounting
Efficacy	up to 159 lm/W at a colour temperature of 4,000 K and a colour rendering index (Ra) > 80
Maximum luminous output	from 1,525 lm to 9,650 lm
Lifetime	150,000 hours L95 maintaining 95 % of the initial luminous flux
Warranty	5 years

Varianty

Model	Dimensions	Power	Luminous flux (NB)*	Multilumen	Weight
LENA ECO+ ABS 60	615 × 98 × 84 mm	11 W	1,525 lm	–	0.9 kg
LENA ECO+ ABS 60	615 × 98 × 84 mm	15 W	2,200 lm	yes	0.9 kg
LENA ECO+ ABS 120	1,175 × 98 × 84 mm	20 W	3,025 lm	–	1.7 kg
		27 W	4,200 lm	yes
		39 W	6,050 lm	yes
		49 W	7,600 lm	–
LENA ECO+ ABS 150	1,455 × 98 × 84 mm	25 W	3,875 lm	–	2.0 kg
		33 W	5,200 lm	yes
		47 W	7,450 lm	yes
		63 W	9,650 lm	–

* The luminous flux already includes losses on the luminaire (we do not state the luminous flux of the LED chips themselves). [4,000 K = neutral white (NB)] Multilumen versions have the luminous flux adjustable in four steps via a switch on the driver; they are factory-set to maximum.

Technical data

Luminaire design

Luminaire body:

dark grey ABS (RAL 7001)

high chemical resistance, UV stability

Diffuser:

translucent acrylic

chemically resistant, UV-stable

Reflector:

white sheet steel (RAL 9003)

Colour temperature

4,000 K

Colour rendering Index

> 80 CRI

Beam angle

120° × 102°

Operating temperature

-25 °C ~ 50 °C

max. 35 – 50 °C depending on version

Operating temperature with emergency module

0 °C ~ 40 °C

Input voltage

AC: 220 – 240 V/50 – 60 Hz

Power factor

0.95

Connection

screwless terminal block

Through-wiring

3, 5 or 7 cores (on request)

1.5 mm², 2.5 mm² on request

Protection rating

IP 66 / IP 69

Impact resistance

IK 06

Protection class

Accessories and mounting

Mounting method

surface-mounted on the ceiling
on the wall
suspended

Luminaire options

Dimming:	on request (DALI)
Emergency lighting module:	on request
Stainless steel diffuser clips:	on request

Downloads

Catalogue sheets	Catalogue sheet – LENA ECO+ ABS luminaire
LDT data	LDT data for the LENA ECO+ ABS luminaire

The LENA ECO+ ABS linear LED light is a chemically resistant dustproof luminaire for demanding industrial environments – production halls, workshops, laboratories, food processing plants and covered outdoor areas. The dark grey ABS base and the translucent acrylic diffuser resist chemicals as well as UV radiation.

Protection rating IP 66 / IP 69 allows cleaning with pressurised water, and the luminaire is HACCP certified for the food industry. It is available in three lengths (60, 120 and 150 cm), with an efficacy of up to 159 lm/W. ML versions offer adjustable luminous flux in four steps (multilumen) via a switch on the driver.

Available on request:

DALI dimming,
an emergency lighting module and
diffuser clips made of stainless steel.

LENA ECO+ ABS guarantees a lifetime of 150,000 hours and significant energy savings. It comes with an extended 5-year warranty.
