Linear LED Light LINUS

The LINUS linear LED luminaire was specially developed for extreme temperatures – thanks to its temperature range it is suitable above all for cold stores, freezer rooms, metallurgical lines, bakeries and glassworks.

SKU: c8595ee40552 Category: LED linear industrial lighting

Features

Key features	ideal replacement for linear T5 and T8 fluorescent tubes suitable for indoor and outdoor use for extreme temperatures from -40 °C up to +75 °C resistance to splashing water and impacts resistance to deformation and aggressive environments dust resistance
Efficacy	up to 135 lm/W at a colour temperature of 4,000 K and a colour rendering index (Ra) > 80
Maximum luminous output	from 3,100 lm to 8,350 lm
Lifetime	50,000 hours L80B10 while maintaining 80 % of the original luminous flux
Warranty	5 years

Varianty

Model	Dimensions	Number of modules in the luminaire (M)	Power	Luminous flux (NW)*	Ambient temperature	Weight
LINUS 120	1,230 × 80 × 110 mm	2	37 W	5,000 lm	-40 °C ~ 70 °C	4.3 kg
LINUS 120	1,230 × 80 × 110 mm	2	53 W	6,825 lm	-40 °C ~ 65 °C	4.3 kg
LINUS 150	1,530 × 80 × 110 mm	1	24 W	3,100 lm	-40 °C ~ 75 °C	5.0 kg
		1	34 W	4,250 lm	-40 °C ~ 70 °C	5.0 kg
		2	46 W	6,125 lm	-40 °C ~ 70 °C	5.3 kg
		2	65 W	8,350 lm	-40 °C ~ 65 °C	5.3 kg

* The luminous flux already includes the losses on the luminaire (we to not state the luminous flux of the LED chips themselves). The intensity of the luminous flux depends on the chosen colour temperature (in kelvins) – the higher the temperature, the higher the luminous flux. [3,000 K = warm white (WW), 4,000 K = neutral white (NW), 5,000 K = daylight white (DW), 6,000 K = cool white (CW)]

Technical data

Luminaire design

Luminaire body:	aluminium profile
Diffuser:	heat-tempered safety glass
Reflector:	white steel sheet
Luminaire sealing:	polyurethane
Clips:	stainless steel

Colour temperature

4,000 K (3,000 K or 5,000 K on request)

Colour rendering index

> 80 CRI

Beam angle

105° x 90°

Ambient temperature

-40 °C ~ 75 °C **

Input voltage

AC: 220 V – 240 V/50 – 60 Hz

Protection rating

IP 66

Impact resistance

IK 10

** The luminaire is suitable for ambient temperatures up to 75 °C (the exception being the luminaire variants with maximum power, which are suitable up to 65 °C or 70 °C; exact temperature data is given in the Varianty tab).

Accessories and mounting

Accessories

stainless steel bracket with suspension clip (included)
surface-mounting bracket (optional)
wall bracket (optional)

Mounting method

surface mounting on the ceiling
surface mounting on the wall
suspension

Luminaire options

Dimming:

on request (DALI)

Emergency lighting module:

on request

operating temperature emergency lighting 0 °C ~ 25 °C

Through-wiring:

on request (1P/3P)

Downloads

Catalogue sheets	Catalogue sheet – LINUS luminaire
LDT data	LDT data for the LINUS luminaire

LED luminaire for extreme temperatures

It is an ideal replacement for linear T5 and T8 fluorescent tubes. It is most often used for surface mounting on the ceiling, or for installation on the wall. The luminaire is suitable for indoor and outdoor use. It is produced in two lengths (120 and 150 cm), in a version with integrated LED chips.

LINUS guarantees a long service life and significant energy savings. You will surely appreciate its parameters – savings of up to 45 % in costs on energy compared to its older fluorescent alternative and a service life of more than 50,000 hours. Thanks to its high luminous efficacy of up to 135 lm/W it can effectively illuminate the space while saving your costs.

The individual light sources (LED chips) are not distinguishable, the luminaire provides pleasant uniform illumination of the space without the effect of multiple shadows. It is characterised by faithful colour rendering, the colour rendering index is higher than 80. In the illuminated space a person thus feels comfortable, undisturbed by distortion of the real colours of objects.

Other characteristics of the LINUS luminaire include dust resistance and high resistance to splashing water and impacts (thanks to the IP 66 protection rating, perfect sealing of the luminaire is guaranteed). The luminaire withstands deformation, aggressive environments and is specially developed for installation in extreme temperatures from -40 °C up to +75 °C. It has instant start, does not buzz and does not flicker.

The luminaire is “photobiologically safe” and belongs to the group “risk-free lighting” – it has no photobiological impact on the human body (skin, cornea) in the case of long-term exposure to its light. It can also be classified as ecological lighting – it does not contain substances harmful to the environment and does not produce UV radiation. The polycarbonate body of the luminaire is made exclusively of safe materials and even in the event of damage you are not at any risk.

LINUS luminaires come with an extended 5-year warranty.
