LED Sensor Light SENZO II

The SENZO II LED ceiling sensor light is a suitable lighting solution for indoor and outdoor areas.

SKU: d6615681f009 Categories: Sensor LED Lights, Wall LED Lights

Features

Key features	integrated microwave motion sensor ceiling or wall mounting thermoplastic body, opal diffuser suitable also for covered exteriors on request decorative cover, emergency module and DALI
Efficacy	up to 122 lm/W at a colour temperature of 4,000 K and a colour rendering index (Ra) > 80
Maximum luminous output	from 1,025 lm to 1,550 lm
Lifetime	50,000 hours L80B10 maintaining 80 % of the initial luminous flux
Warranty	5 years

Varianty

Model	Dimensions	Power	Luminous flux (TB)*	Luminous flux (NB)*	Weight
SENZO II 9	Ø 295 × 100 mm	9 W	1,025 lm	1,100 lm	1.1 kg
SENZO II 14	Ø 295 × 100 mm	14 W	1,475 lm	1,550 lm	1.1 kg

* The luminous flux already includes losses on the luminaire (we do not state the luminous flux of the LED chips themselves). The luminous flux depends on the selected colour temperature (in kelvins) – the higher the temperature, the higher the luminous flux. [3,000 K = warm white (TB), 4,000 K = neutral white (NB)]
With the decorative cover the luminous flux is 600 / 625 lm (SENZO II 9) and 875 / 925 lm (SENZO II 14).

Technical data

Luminaire design

Luminaire body:	white thermoplastic
Diffuser:	opal acrylic (PMMA), UV-stable

Colour temperature

3,000 K or 4,000 K

Colour rendering Index

> 80 CRI

Beam angle

120°

Sensor

microwave (MW), on/off

Operating temperature

-15 °C ~ 35 °C

with emergency module 0 °C ~ 35 °C

Input voltage

AC: 220 – 240 V/50 – 60 Hz

Power factor

> 0.95

Protection rating

IP 65

Impact resistance

IK 08

Protection class

Accessories and mounting

Mounting method

surface-mounted on the ceiling
on the wall

Luminaire options

Decorative cover:	on request
Dimming:	on request (DALI)
Emergency lighting module:	on request (3 h)

Downloads

Catalogue sheets	Catalogue sheet – SENZO II luminaire
LDT data	LDT data for the SENZO II luminaire

The SENZO II LED sensor light is a suitable lighting solution for indoor and covered outdoor areas – corridors, staircases, entrances and sanitary facilities. The integrated microwave motion sensor switches the luminaire on only when needed, which brings significant energy savings.

The LED chips are placed directly in the luminaire body, so no bulb needs to be installed and installation is very simple. The luminaire switches on instantly at 100 %, produces no UV radiation (does not attract insects) and causes no delayed start, flickering or stroboscopic effect. Protection rating IP 65 allows installation in covered outdoor areas too.

Available on request:

a version with a decorative cover,
an emergency lighting module and
DALI lighting control.

SENZO II guarantees a lifetime of 50,000 hours. It comes with an extended 5-year warranty.
