Wall LED Light NOVA

NOVA is an energy-saving lighting solution for building facades, footpaths, balconies and other public spaces.

Features

Key features	round or square shape light distribution upwards and downwards 36° reflectors, 60° on request high-quality aluminium body and toughened glass diffuser wall mounting, ceiling mounting on request
Efficacy	up to 96 lm/W at a colour temperature of 4,000 K and a colour rendering index (Ra) > 80
Maximum luminous output	from 975 lm to 2,450 lm
Lifetime	50,000 hours L80B50 maintaining 80 % of the initial luminous flux
Warranty	5 years

Varianty

Model	Dimensions	Power	Luminous flux (TB)*	Luminous flux (NB)*	Weight
NOVA 13 – round	130 × 90 × 220 mm	13 W	1,200 lm	1,250 lm	1.1 kg
NOVA 27 – round	155 × 110 × 260 mm	27 W	2,075 lm	2,150 lm	1.6 kg
NOVA 13 – square	130 × 86 × 180 mm	13 W	975 lm	1,000 lm	1.3 kg
NOVA 27 – square	170 × 118 × 220 mm	27 W	2,350 lm	2,450 lm	2.0 kg

* The luminous flux already includes losses on the luminaire (we do not state the luminous flux of the LED chips themselves). The luminous flux depends on the selected colour temperature (in kelvins) – the higher the temperature, the higher the luminous flux. [3,000 K = warm white (TB), 4,000 K = neutral white (NB)]

Technical data

Luminaire design

Luminaire body:	grey aluminium (RAL 7043)
Diffuser:	toughened glass

Colour temperature

3,000 K or 4,000 K

Colour rendering Index

> 80 CRI

Beam angle

36° + 36°

60° + 60° on request

Operating temperature

-30 °C ~ 45 °C

Input voltage

AC: 220 – 240 V/50 – 60 Hz

Power factor

> 0.85

Protection rating

IP 65

Impact resistance

IK 08

Protection class

Accessories and mounting

Mounting method

surface-mounted on the wall
surface-mounted on the ceiling (on request)

Downloads

Catalogue sheets	Catalogue sheet – NOVA luminaire
LDT data	LDT data for the NOVA luminaire

The NOVA LED light is a modern and elegant lighting solution for building facades, entrances, terraces, balconies, footpaths and commercial outdoor areas. It emits light upwards and downwards at the same time, creating a striking lighting effect on the facade.

It is available in a round or square shape and is designed for wall mounting. A version for ceiling mounting is available on request. As standard it has reflectors with a beam angle of 36°, 60° on request.

NOVA guarantees a lifetime of 50,000 hours and significant energy savings. It comes with an extended 5-year warranty.
