High Efficiency LED High Bay Light PRIMUS

A highly efficient and resistant LED High Bay Light. Perfect for production sites, warehouses, factories and workshops.

Category: LED High Bay Lights

Features

Key features	ideal lighting for spaces with high ceilings optimal heat dissipation and luminaire cooling durable luminaire suitable for industrial environments
Efficacy	up to 197 lm/W at colour temperature 4,000 K and colour rendering index (Ra) > 80
Maximum luminous output	from 16,500 lm to 38,325 lm
Lifetime	131,000 hours L70B50 maintaining 70 % of the original luminous flux, or 70,000 hours L80B50 maintaining 80 % of the original luminous flux
Warranty	5 years

Varianty

	Dimensions	Power	Luminous flux		Weight
	Dimensions	Power	60° (NB)*	90° (NB)*	Weight
PRIMUS 86	Ø 260 × 120 mm	86 W	16,500 lm	16,925 lm	1.9 kg
PRIMUS 118		118 W	22,225 lm	22,825 lm
PRIMUS 150		150 W	27,825 lm	28,575 lm
PRIMUS 200	Ø 300 × 120 mm	200 W	37,300 lm	38,325 lm	2.3 kg

* The luminous flux already includes the losses on the luminaire (we do not state the luminous flux of the LED chips themselves). The luminous flux intensity depends on the selected colour temperature (in kelvins) – the higher the temperature, the higher the luminous flux. [3,000 K = warm white (WW), 4,000 K = neutral white (NW), 5,000 K = daylight white (DW), 6,000 K = cool white (CW)]

Other beam angles, colour temperatures and a colour rendering index of Ra 90 are also available on request.

Technical data

Other beam angles are available on request.

order-collapse: collapse;”>

Colour temperature

4,000 K (3,000 K and 5,000 K on request)

Colour rendering index

> 80 CRI (Ra 90 on request)

Beam angles

90°
60°

Operating temperature

-30 °C ~ 50 °C

Input voltage

AC: 220 V – 240 V/50 – 60 Hz

Protection rating

IP 65

Impact resistance

IK 08

Accessories and mounting

Accessories

AL diffuser (UGR 22)
PC diffuser
sensor controller
surface-mounting bracket
suspension accessories

Mounting method

surface-mounted (bracket)
suspended (hanging eye)

Luminaire options

Dimming:

DALI, DALI 2, 0 – 10 V,

Sensors: HF sensor, PIR sensor

Downloads

Catalogue sheets	Catalogue sheet – PRIMUS luminaire
LDT data	LDT data for the PRIMUS luminaire

Efficacy of the PRIMUS luminaire is truly exceptionally high – up to 197 lm/W at colour temperature 4,000 K and colour rendering index (Ra) higher than 80. It is ideal for lighting spaces with high ceilings.

The saving when replacing old lighting with the PRIMUS LED industrial luminaire amounts to up to 80 % of energy costs . The luminaire lifetime is 131,000 hours (L70B50) – i.e. maintaining 70 % of the original luminous flux or 70,000 hours (L80B50).

The finned passive heatsink of the LED chips, together with additional passive cooling of the electronic driver, ensures optimal heat dissipation and luminaire cooling. The luminaire consists of high-quality components, is durable and suitable for industrial environments. The IP 65 protection rating ensures that the luminaire can be installed without problems outdoors as well.

Surface and suspended mounting allow the luminaire to be used in various installations. PRIMUS produces no UV radiation and does not attract insects, is environmentally friendly, requires no maintenance, and during operation there are no issues with delayed start-up, flickering or high-frequency interference.

PRIMUS represents a high-quality and reliable lighting solution. The production process is strictly controlled and the luminaire is continuously tested. The luminaire comes with an extended 5-year warranty.

The luminaire is in stock; the delivery time is 1–2 working days from receipt of the order.
