Mini LED panel DANIEL – square

Its biggest advantages are 60 % saving on your energy and maintenance costs and a lifespan of 50,000 hours.

Simple installation due to low mounting height (25 mm). Mini LED Panel DANIEL can be installed into drop ceiling so its elegant frame shows nicely.

The fixture emits pleasant even light without shading. Opal diffuser lowers the losses of light intensity. It is characteristic by the true colour rendering, as the colour rendering index is higher than 80.

Mini LED Light DANIEL does not emit any UV radiation, does not attract the insect nor flicker, its operation is environmentally friendly, maintenance free, it switches on immediately and no radio frequency disturbance occurs.

We provide 3 years warranty.

MINI LED PANEL DANIEL – ROUND PARAMETERS

MODEL	Mini panel DANIEL – round S	Mini panel DANIEL – round M	Mini panel DANIEL – round L
Input voltage	230 V (AC/DC)
Size	120 × 120 mm	172 x 172 mm	225 x 225 mm
Height	25 mm
Input	9 W	15 W	21 W
Light flux (NW)*	800 lm	1,500 lm	2,000 lm
Colour temperature	2,700 K, 4,000 K or 5,000 K
Colour rendering index	> 80 CRI (Ra)
Power factor	> 0.95
Enclosure rating	IP 40 (optics)⁄IP 20 (electrics)
Protection rating	II
Operation time	> 50,000 hrs
Operation temperature	-5 °C ~ 35 °C
Body material	Aluminium profile varnished – RAL 9003
Diffuser	opal
LED	Everlight
Driver	Eaglerise
Control options	DALI or 1-10 V
Mounting options	urecessed into drop ceiling/plaster board
Weight	0.4 kg	0.6 kg	0.8 kg
Warranty	3 years

*  Light flux parameter shows the REAL light flux regarding the light intensity loss (not the LED chip light flux intensity, which does not reflect the real light intensity). Light flux intensity depends on the temperature employed (K), higher the temperature, higher the light flux. [3,000 K = warm white (WW), 4,000 K = neutral white (NW), 5,000 K = day light white (DW), 6,000 K = cold white (CB)]
